BIG-BAG carrier KR-BIG

The BIG-BAG handle is used to transport big bags (BIG-BAGs).

Get a Quote

Detailed Description

The BIG-BAG handle is used to transport big bags (BIG-BAGs). The accessory is suitable for all types of carrier vehicles, such as loaders, mini loaders, tractors with front loaders and telescopic loaders. The design allows the bag to be positioned in a convenient position and offers a very safe, comfortable handling system and good visibility. The robust construction of the device ensures safety during work. The handle has a standard height of 1.2 m and an arm length of 1 m. Equipped with 4 hooks with secure locking and a load capacity of 2 tonnes.

Standard Equipment:

The big bag carrier is suitable for transporting loaded BIG BAG bags.
The equipment is specialised for all types of media, i.e. loaders, skid steer loaders, tractors with front loaders, etc.
The hook is mounted vertically on an adjustable arm. This allows you to place the bag in the required position. Good visibility and a secure, comfortable grip system ensure flawless use of the big bag carrier during work.
The position is also held by the side arms.
Careful construction of the equipment guarantees user safety during operation.

Optional Equipment:

Galvanised construction,
Any fastening,
Other dimensions,
Adjustable height from 1.2 to 1.8 m,
Side protection tubes, to prevent the sack from tipping over while driving,
Increased load capacity.

Technical Specifications

INDEX	WIDTH (M)	HEIGHT (M)	ARM LENGTH (MM)	LOAD-BEARING CAPACITY (KG)	WEIGHT (KG)
KR-BIG-1200	1,10	1,20	1100	1200	95
KR-BIG-1500	1,10	1,50	1100	1200	105
KR-BIG-1800	1,10	1,80	1100	1200	115
KR-BIG-12-18	1,10	1,20-1,80	1100	1200	135
